B & C Speakers 18 in. 2400W 8 ohm Continuous Power Subwoofer HDS_VB49254

$39.00  $7.04




Product details:

The industry-standard B&C Speakers 18TBX100 features a 1" long/4" diameter copper wire voice coil with high thermal capability, and a ventilated magnet assembly, both of which contribute to low power compression. A very low distortion figure is obtained using a double spider design and dual demodulation rings in the magnetic path. The 18TBX100 is fortified by a proprietary water-proof cone treatment that facilitates safe use in adverse climatic conditions. This benchmark pro subwoofer driver is found in many famous manufacturers' well-established loudspeaker enclosures.

Features
  • Dual demodulation rings in the magnet system
  • 4" copper wire voice coil wound inside-outside on fiberglass former
  • Double spider suspension system maintains linearityDouble spider suspension system maintains linearity
  • Very low distortion-nothing but deep, clean bass
  • Voice Coil Former Fiberglass
Specifications
  • Nominal Diameter: 18 in.
  • Power Handling (RMS): 1,200 Watts
  • Power Handling (max): 2400 Watts
  • Impedance: 8 ohms
  • Frequency Response: 35 to 1,000 Hz
  • Sensitivity: 97 dB 2.83V/1m
  • Voice Coil Diameter: 4 in.
  • Resonant Frequency: 34 Hz
  • DC Resistance: 5.1 ohms
  • Voice Coil Inductance: 1.6 mH
  • Mechanical Q (Qms): 7.2
  • Electromagnetic Q (Qes): 0.37
  • Total Q (Qts): 0.35
  • Compliance Equivalent Volume: 8.9 ft.
  • Maximum Linear Excursion: 9 mm
  • Cone Material: Paper
  • Surround Material: Cloth
  • Voice Coil Wire Material: Copper
  • Magnet Material: Ferrite
  • Baffle Cutout Diameter: 16.6 in.
  • Depth: 8.2 in.
  • Bolt Circle Diameter: 17.3 in.
  • Weight: 32 lbs
- SKU: TNSR8744
Features:vehicle-subwoofers
Brand:B&C Speakers
Manufacturer Part Number:18TBX100-8
Manufacturer:B&C Speakers
Model:18TBX100-8
